| Tire Size | Ply Rating | Standard Rim | Inflated size of new tire (mm) | Maximum Load (Kg) | Relative Pressure | Remark | |||
| Section Width | Overall Diameter | 50km/h | 10km/h | 50km/h | 10km/h | ||||
| 24.00-35 | 36 | 17.00/3.5 | 650 | 2178 | 15500 | 26500 | 475 | 650 | TL |
| 42 | 17.00/3.5 | 650 | 2178 | 16500 | 29000 | 550 | 750 | TL | |
| 48 | 17.00/3.5 | 650 | 2178 | 18500 | 31500 | 650 | 850 | TL | |
| 54 | 17.00/3.5 | 650 | 2178 | 19500 | 34500 | 725 | 975 | TL | |
| 24.00-49 | 36 | 17.00/3.5 | 650 | 2531 | 18500 | 32500 | 475 | 650 | TL |
| 42 | 17.00/3.5 | 650 | 2531 | 20000 | 34500 | 500 | 750 | TL | |
| 48 | 17.00/3.5 | 650 | 2531 | 21800 | 37500 | 650 | 850 | TL | |
| 27.00-49 | 36 | 19.50/4.0 | 735 | 2703 | 21200 | 36500 | 425 | 575 | TL |
| 42 | 19.50/4.0 | 735 | 2703 | 23000 | 40000 | 500 | 675 | TL | |
| 48 | 19.50/4.0 | 735 | 2703 | 25000 | 43700 | 575 | 775 | TL | |
